= Basic Configuration

Introduction

This manual describes the basic configuration and functionality of the Core application in Android environment.

Customer List and Customer Tasks parameters

Parameter (configuration)	Description
CUSTOMERLISTXML	XML for Customer List display customization
BLOCKVISITSQL	Contains the SQL query, the result of which determines if a specific client may be selected from the grid. The SQL query should return the fields: Result and MessageText. Replaces the $TODAY$ and $CUSID$
sqlOffGetCustomerTasks	The SQL to be executed to bring the customer-specific tasks in offline mode. Replaces the $CUSID$ and $SLMID$ [Mandatory]
sqlOffGetCustomerTasksSimpleVisit	The SQL to be executed to bring the customer-specific tasks in offline mode in case of simple visit. Replaces the $CUSID$, $SLMID$ and $SIMPLEVISITSLMTASKID$ [Mandatory]
sqlOffGetCustomerDetails	The SQL to be executed to bring the customer-specific information details in offline mode. Replaces the $CUSID$, $SLMID$, $ADRIDDEST$
SimpleVisitSLMTaskID	If it is 0 it doesn't appear the option for simple visit. If it is set, then in customer information displays and the option for simple visiting with the actions (tasks) of the corresponding slmtaskid
CUSBalanceXML	the xml that overrides the default, which is responsible for the design of the financial data grid.
kartelles	0 (default), 1 displays all extra financial customer info (DSO, open balance)
SQLFINANCIAL	If it has an extraconfigvalue (SQL), checks which fields will appear in the financial tab (overrides default)

Formatting the Customer List

Depending on the list, we have to place the appropriate XML into the CustomerListXML parameter in the Configuration table:

Parameter name	Description
CUSTOMERLISTXML	XML for Customer List display customization

The XML supports rows and column. Badges are also supported. The field coordsx and the field coordsy must be completed to show the spots on the map.

Attention: After each change in the XML, must synchronize (in offline mode) and force stop the application (in every case).

The general format of the XML is as follows:

<sql>
<online
query="..." routequery="..." near="..." />
<offline
query="..."
routequery="..."
near="..." />
</sql>
<columns>
<column minWidth="300" position="1">
<row datamember="..." textsize="…" color="…" />
<row datamember="…" textsize="…" color=".." />
<row datamember="..." color="…" />
<row ….. />

</column> <column …. </column>

</columns>
<filters>
<filter caption="..." replacetoken="..." fieldname="..."
includefieldname="..." fieldtype="..." SQL="select … as displayvalue, … as storevalue from …. where …." Alphabetreplace=”1”/>
<filter ….. /> </filters>

</AndroidLayout>

TAG <sql>:

INNER TAGS: online for online queries OPTIONAL
and offline for offline queries. REQUIRED

query: the select sql query to execute. REQUIRED
routequery: the select sql query, if the user has selected to filter the customer list based to route (checkbox in the list and date selection). Leave blank " " if route option is not required. For the date tha the user has selected, use the $DATE$. REQUIRED
near: the select sql query we want to be replaced in the parameter $NEAR$ of the above sql. Leave blank " " to disable it, if it is not a desirable option. REQUIRED
maxrecords: determines the maximum number of rows that will appear on the grid. (default value is 300 rows). If dataset rows > maxrecords then the grid will populated only with the first rows and a relative message will inform user that he have to input some criteria.

Note: In any case the required fields are: cusid, leename, addriddest
+ any other required field from the modules (field service)

TAG <columns>:

INNER TAGS: Every column shows field values from a record in the result dataset. REQUIRED at least 1.

<column>:

minWidth: like "250", sets the minimum width of the column. REQUIRED
position: sets the position of the column like "1". REQUIRED

TAG <rows>:

INNER TAGS: Every row displays a line included as a record in the result dataset. REQUIRED at least 2.
<row>:

datamember: displays the field value from the select query. REQUIRED
textsize: the size of the font. OPTIONAL
color: the color of the row. OPTIONAL, usefull website: http://cloford.com/resources/colours/500col.htm
useInSearch='true' : If you put in each row the useInSearch = 'true', you will be able to do a search in this field through the General search (regardless of filters). If you don't put in any row the useInSearch = ‘true’, the General search, will be looking only at leename. (the General search looking like ‘contains in each field’).
badge="badge1" : For each customer, there is a similar color badge so customer list and map. The Badge color is apparent from the company that the customer works. See next chapter about Badges.

NOTE: the first row has a bold font. From the 3^rd line and after we could change the color.

TAG <filters>:

INNER TAGS: Every filter shows an additional filter for searching replaced in the select. OPTIONAL
<row>:

caption: the name that will appear as a description of the filter. REQUIRED

replacetoken: The token that will be replaced in sql $ ... $ from what you will write the user. REQUIRED
includefieldname: values - "0" or "1". REQUIRED
- If "1" then the criterion is manufactured using this fieldname as follows: {fieldname} = {user value}. If "1" and the user leave the criterion blank then the token is replaced with 1 = 1, otherwise with {fieldname} = {user value}.
- If "0" then the criterion be replaced directly with the value put the user, without having to add field name. If the user leaves it blank then the token is replaced with blank.
- ATTENTION: SQL filter with parameter includefieldname = 0 not supported.

fieldname: the name of the field which will replace in sql. REQUIRED (if includefieldname=1)
fieldtype: values INT, NVARCHAR, FLOAT, SQL (used to populate options list), SEARCHABLE_LIST_TYPE, MULTI_SELECT_LIST_TYPE, BOLLEAN (In case True the replaced values is(1=1), in case False(1=0) ). The input that will be available to the user. REQUIRED
SQL : The sql query to be executed to bring all available options for the user. REQUIRED (if fieldtype=SQL)

displayvalue : the value that will be visible to the user when selecting REQUIRED
storevalue : the value to be replaced in the select REQUIRED

alphabetreplace: 0/1 replacement characters for greeklish and case insensitive searches. See. Greek support in search

NEW FITERS TYPE ESSENTIAL NOTES

For filters type SEARCHABLE_LIST_TYPE and MULTI_SELECT_LIST_TYPE when the

includefieldame = 1 then the TOKEN will replace with values with id. That values comes from SQL (display values, store values).

Example:

<filter caption="Δ.Ο.Υ" replacetoken="$TXOID$" fieldname="lee.txoid" includefieldname="1" fieldtype="MULTI_SELECT_LIST_TYPE" SQL="select txoname as displayvalue,txoid as storevalue from txo order by txoname" keepvalue="1"/>

The replaced token will become lee.txoid IN (151142, 454752, 5475,…).

In case the filter have empty value then the token will become (1 = 1)

When the includefieldname = 0 then the TOKEN will be replace with strings .That values comes from SQL (display values, store values).

Example:

<filter caption="Πόλη" replacetoken="$CITY$" fieldname="adr.adrcity" includefieldname="0" fieldtype="MULTI_SELECT_LIST_TYPE" SQL="select distinct adrcity as displayvalue, adrcity as storevalue from ADR order by adrcity" keepvalue="1"/>

The replaced token will become with strings IN (΄ΘΕΣΣΑΛΟΝΙΚΗ΄, ΄ΠΑΤΡΑ΄, ΄ΑΙΓΙΟ΄,….).

In case the filter have empty value then the token will become LIKE΄%΄

The same functionalities is for the filter SEARCHABLE_LIST_TYPE.

ATTENTION:

1) In case we want to replace SQL filter with one of the above fitlers need to be careful the syntax in offline query with the replaced token.

Example: <offlinequery=”SELECT…FROM…WHERE like $TXOID$ and ifnull(adr.adrcity,) like '$CITY$%' … ”

Then the replaced token with above filters will faill to do the query because of the replacement.

The query will become

SELECT…FROM…WHERE like IN(245444,45774,….) and ifnull(adr.adrcity,) like 'LIKE IN(΄ΘΕΣΣΑΛΟΝΙΚΗ΄, ΄ΠΑΤΡΑ΄, ΄ΑΙΓΙΟ΄,….)'.

Need to reconstruct the offlinequery to become like that

<offlinequery=SELECT…FROM…WHERE $TXOID$ and ifnull(adr.adrcity,) $CITY$...

Now the query will become

SELECT…FROM…WHERE IN(245444,45774,….) and ifnull(adr.adrcity,) LIKE IN(΄ΘΕΣΣΑΛΟΝΙΚΗ΄, ΄ΠΑΤΡΑ΄, ΄ΑΙΓΙΟ΄,….).

2) Becerful the displays values not include comma sperated values. Example of display values «Α, Β, Γ ΑΘΗΝΩΝ», this value not allowed and must be convert in other format like «Α-Β-Γ ΑΘΗΝΩΝ».

TAG <map>:

<map badge='badge1' subtitle=’revenue’/>

Specifies the color of the dot will appear on the map in the client coordinates. The subtitle defines what will be displayed if the user clicks on it.

XML example 1 (queries, near)

<sql>
<online query="exec mobGetCustomers $SLMID$,null, $LAT$, $LONG$"
routequery="exec mobGetCustomers $SLMID$, $DATE$, $LAT$, $LONG$"
near="(CentroidX between abs( $LAT$ - (10 * 0.009)) and abs( $LAT$ + (10 * 0.009)))" />
<offline query="SELECT cusid,leename,adriddest, adrstreet as destadrstreet,adrnumber as destadrnumber,adrcity as destadrcity, IFNULL(adrstreet,) || ' ' ||
IFNULL(adrnumber,) || ' ' || IFNULL(adrzipcode,) || ' ' || IFNULL(adrdistrict,) AS destaddress,adrzipcode as destadrzipcode,adrdistrict as destadrdistrict,centroidx as coordsx, centroidy as coordsy, case when exists (select visitid from tblVisits where cusid=CUS.cusid and date(starttime)=$TODAY$) then 1 else 0 end as visited from CUS INNER JOIN LEE ON CUS.leeid=LEE.leeid INNER JOIN ADR ON ADR.adrid=CUS.adriddest where (cus.slmid=$SLMID$ or cus.slmid2=$SLMID$ or cus.slmid3=$SLMID$) and $NEAR$"
routequery="SELECT cusid,leename,adriddest,adrstreet as destadrstreet,adrnumber as destadrnumber,adrcity as destadrcity, IFNULL(adrstreet,) || ' ' ||
IFNULL(adrnumber,) || ' ' || IFNULL(adrzipcode,) || ' ' || IFNULL(adrdistrict,) AS destaddress, adrzipcode as destadrzipcode,adrdistrict as destadrdistrict,centroidx as coordsx, centroidy as coordsy, case when exists (select visitid from tblVisits where cusid=CUS.cusid and date(starttime)=$TODAY$) then 1 else 0 end as visited from CUS INNER JOIN LEE ON CUS.leeid=LEE.leeid INNER JOIN ADR ON ADR.adrid=CUS.adriddest where (cus.slmid=$SLMID$ or cus.slmid2=$SLMID$ or cus.slmid3=$SLMID$) and (CUS.cusid=$CUSID$ or $CUSID$=0) and $NEAR$"
near="( CentroidX between abs( $LAT$ - (10 * 0.009)) and abs( $LAT$ + (10 * 0.009))) and (CentroidY between abs( $LONG$ - (10* 0.011)) and abs( $LONG$ + (10 * 0.011)))\" />
</sql>
<rows>
<row datamember='leename' textsize='25' color='#FFFF00'/>
<row datamember='destaddress' textsize='20' color='#FFFFFF'/>
</rows> </AndroidLayout>

XML example 2 (show datamembers)

<offline query="SELECT cus.cusid,leename, adriddest, adrstreet as destadrstreet,adrnumber as destadrnumber,adrcity as destadrcity, IFNULL(adrstreet,) AS destaddress,'Cus. Code:' || ifnull(cus.cuscode,) as extrainfo, adrzipcode as destadrzipcode, 'Tel: '|| ifnull(adr.adrphone1,) as adrphone1,adrdistrict as destadrdistrict,centroidx as coordsx, centroidy as coordsy, cus.udfint1 as badge, case when exists (select visitid from tblVisits where cusid=CUS.cusid and date(starttime)=$TODAY$) then 1 else 0 end as visited from CUS INNER JOIN LEE ON CUS.leeid=LEE.leeid INNER JOIN ADR ON ADR.adrid=CUS.adriddest where cus.cusid not in (-1,-2) order by leename "

routequery="... inner join tblRouteScheduledLines on tblRouteScheduledLines.cusid=cus.cusid and tblRouteScheduledLines.scheduledDate=$DATE$ where cus.cusid not in (-1,-2) order by leename" near="" /></sql>

<row datamember='leename' textsize= color='#0a4879' useInSearch='true'/>

</column > <column minWidth="1" position="2">

<row datamember='destaddress' textsize= color='#1c75bc' useInSearch='true'/>

</column > <column minWidth="1" position="3"> <row datamember='destadrcity' textsize= color='#1c75bc' useInSearch='true' badge="badge"/> </column > </columns>

XML example 3 (badge stored in the customer row)

<offline query="SELECT cus.cusid,leename, adriddest, adrstreet as destadrstreet,adrnumber as destadrnumber,adrcity as destadrcity, IFNULL(adrstreet,) AS destaddress,'Cus. Code:' || ifnull(cus.cuscode,) as extrainfo, adrzipcode as destadrzipcode, 'Tel: '|| ifnull(adr.adrphone1,) as adrphone1,adrdistrict as destadrdistrict,centroidx as coordsx, centroidy as coordsy, cus.badge as badge, case when exists (select visitid from tblVisits where cusid=CUS.cusid and date(starttime)=$TODAY$) then 1 else 0 end as visited from CUS INNER JOIN LEE ON CUS.leeid=LEE.leeid INNER JOIN ADR ON ADR.adrid=CUS.adriddest where cus.cusid not in (-1,-2) order by leename "

routequery="... inner join tblRouteScheduledLines on tblRouteScheduledLines.cusid=cus.cusid and tblRouteScheduledLines.scheduledDate=$DATE$ where cus.cusid not in (-1,-2) order by leename" near="" /> </sql> <columns>

<row datamember='leename' textsize= color='#0a4879' useInSearch='true'/>

</column >

<row datamember='destaddress' textsize= color='#1c75bc' useInSearch='true'/>

</column >

<row datamember='destadrcity' textsize= color='#1c75bc' useInSearch='true' badge="badge"/>

</column > </columns>

<map badge='badge' subtitle='tziros'/>

</AndroidLayout>

The Cus table has already a field named badge for each customer. Another scenario is a custom field like cus.udfint1 as badge

Eg. …CASE WHEN ifnull(udfint3, 1) =1 THEN 7 WHEN ifnull(udfint3, 1) =3 then 18 else 25 END AS badge

XML example 4

<offline query="SELECT cus.cusid,ifnull(cus.cusname,leename) as leename,cusname,adriddest,ifnull(adr.CentroidX,) as Coordsx,ifnull(adr.CentroidY,) as CoordsY,'Πόλη: ' || IFNULL(adrcity,) as destadrcity, IFNULL(adrstreet,) AS destaddress,IFNULL(adrdistrict,)as adrdistrict,'Κωδ. Πελάτη: ' || ifnull(cus.cuscode,) as extrainfo,'Α.Φ.Μ: '||ifnull(lee.leeafm,)as leeafm, 'Τηλέφωνο: '|| ifnull(adr.adrphone1,) as adrphone1,'Τ.Κ.: ' || ifnull(adrzipcode,) as adrzipcode,ifnull(adr.adremail,) as email, case when exists (select visitid from tblVisits where cusid=CUS.cusid and date(starttime)=$TODAY$) then 1 else 0 end as visited,SLMtasklistid as cusslmtasklistid,cus.badge as badge1,'Τζίρος: '|| ifnull(cus.tziros,0) as tziros,Companies.CompanyDescr as Company from CUS INNER JOIN LEE ON CUS.leeid=LEE.leeid INNER JOIN ADR ON ADR.adrid=CUS.adriddest LEFT OUTER JOIN CustomKriKriCompanies Companies ON Companies.KrikriCompanyID=CUS.CompanyID where cus.cusid not in (1,2,3,4,-1,-2) and $RouteID$ and $CUSCategoryID$ and ( ifnull(cus.tziros,0)>= cast(ifnull(nullif('$tzirosMegaluteros$',),-100000)as int) and cast(ifnull(nullif('$tzirosMikroteros$',),100000000)as int )>=ifnull(cus.tziros,0) ) order by leename,cuscode " routequery="" near="" /></sql>

</column >

</column >

</column >

</columns>

<filter caption="Τζίρος > :" replacetoken="$tzirosMegaluteros$" fieldname="cus.RouteID" includefieldname="0" fieldtype="FLOAT" SQL="" keepvalue="1" />

</filters>

</AndroidLayout>

Another example of filters:

<filters>
<filter caption="Επων-Διευθ-Περιοχ-ΑΦΜ:" replacetoken="$MultiFilter$" fieldname="" includefieldname="0" fieldtype="NVARCHAR" SQL="" alphabetreplace="1"/>
</filters>

Badges (on Tasklist, Customerlist etc)

Show custom coloured badge (colored dot) in the client task, or Customerlist, or map etc.

Tasklist:

You must bring in the question of sqlOffGetCustomerTasks a parameter column named Badge with values from 1 to 26. These values correspond to the colors in the table below.

Customerlist:

just populate the xml tag badge with appropriate badge color like badge="badge1"

Badge	Hex code	Name
1	#F0A3FF	Amethyst
2	#0075DC	Blue
3	#993F00	Caramel
4	#4C005C	Damson
5	#191919	Ebony
6	#005C31	Forest
7	#2BCE48	Green
8	#FFCC99	Honeydew
9	#808080	Iron
10	#94FFB5	Jade
11	#8F7C00	Khaki
12	#9DCC00	Lime
13	#C20088	Mallow
14	#003380	Navy
15	#FFA405	Orpiment
16	#FFA8BB	Pink
17	#426600	Quagmire
18	#FF0010	Red
19	#5EF1F2	Sky
20	#00998F	Turquoise
21	#E0FF66	Uranium
22	#740AFF	Violet
23	#990000	Wine
24	#FFFF80	Xanthin
25	#FFFF00	Yellow
26	#FF5005	Zinnia

The color values with their description are also in the [tblBadgeColor] table.

Other sources :

http://en.wikipedia.org/wiki/Help:Distinguishable_colors

Customer Card (extra financial data)

Refers to the ability to display extra financial data (Days Sales Outstanding - DSO, Open value Balance) of the selected customer in the financial tab.
The data comes from the table tblKarteles, (per branch CUSid - not LEEid)
To activate it, put into the configuration, the parameter Kartelles with 1 as configvalue.
Parameter CUSBalanceXML: the xml that overrides the default, which is responsible for the design of the financial data grid There is no option to change the select sql query, only the customization of the columns derived from the tblkarteles. By default the app adds a column named “Running Balance” which is the growing balance of each row. It can be viewed at any location within the grid by putting as datamember=”runningbalance”. Example:
<AndroidLayout><columns>
<column width="120" position="1" caption="Date" datamember="TRNDate"/>
<column width="120" position="2" caption="Document" datamember="TRNReason"/>
<column width="100" position="3" caption="Charge" datamember="Charge"/>
<column width="100" position="4" caption="Credit" datamember="Credit"/>
<column width="120" position="5" caption="Document No" datamember="DosCode"/>
<column width="120" position="6" caption="Due Date" datamember="udfdate1"/>
<column width="120" position="7" caption="Weighted Avg" datamember="udfdate2"/>
<column position="8" caption="Amount" datamember="udffloat1"/>
</columns> </AndroidLayout>

Old not supported: AGINGALGORITHM,ENILPERIOD1..3

By using the SQLFINANCIAL parameter (Configuration table) we can check which fields will appear in the financial tab. For example we can write an SQL as extraconfigvalue:

SELECT 'VAT no' AS title, leeafm AS displayvalue , 1 AS position FROM cus INNER JOIN lee ON cus.leeid = lee.leeid WHERE cusid = $CUSID$ UNION ALL SELECT 'Last Visit' AS title ,date(max(visittime)) AS displayvalue ,2 AS position FROM tblVisits WHERE cusid= $CUSID$ UNION ALL SELECT 'Turnover' AS title ,cus.tziros AS displayvalue ,10 AS position FROM CUS WHERE cusid = $CUSID$ UNION ALL SELECT 'Credit Limit' AS title ,CUS.cuscreditlimit AS displayvalue ,20 AS position FROM CUS WHERE cusid = $CUSID$ UNION ALL SELECT 'Balance' AS title ,CUS.balance AS displayvalue ,30 AS position FROM CUS WHERE cusid = $CUSID$

(optional): 0 as after (default) our custom fields will be displayed before the default financial fields (such as DSO)

or 1 as after : will be displayed after the default financial fields

We can have any combination of the parameters KARTELLES and SQLFINANCIAL. If SQLFINANCIAL parameter has no value, it displays by default:

• If we have not any aging balances, Turnover, Credit Limit and Balance fields (from CUS)

• If we aging balances, except Tab Fields (DSO) appear and the Turnover and Credit limit fields. The balance of the CUS does not appear, because the balance of the tab appears

sqlOffGetCustomersTasks (configuration)

This parameter defines the tasks that will be in the visit of the seller for the selected customer.

We can define additional column named Badge (with values from 1 to 26) for showing specific colors. Attention: not NULL value in the field Badge

Relative Tables:
tblSLMTaskLists, tblSLMTasks
Example:
SELECT SLMTaskID,TaskDescription,Action,MerchScenarioID,MerchCategoryID
,MerchCompanyID,SurveyID,Pos,ParentSLMTaskID,Mandatory
,sdtid,Badge,ActionParameter1
FROM tblSLMTasks
WHERE SLMTaskListID = (
SELECT IFNULL(CUS.SLMTaskListID,
(SELECT configvalue FROM Configuration
WHERE configcode = 'SLMTaskListID' LIMIT 1))
FROM CUS WHERE CUS.cusid = $CUSID$)
ORDER BY Pos ASC
… UNION all SELECT 'ΣΥΝΤΑΓΕΣ ΤΕΧΝΙΚΟΎ','SURVEY',0,0,0,6,15,NULL,0,NULL,0 FROM SLM WHERE SLMID IN (1266758136,1868789165)

Customer Actions in tasklist (tblSLMTasks)

TaskDescription	Action
Order	SalesPlus
Collection	Collection
Pricing Survey (new)	Merchandise
Survey (old)	Survey
Photo	PhotoPlus
Geocoding	Location_Map
Expenses	Benchmarks
Document view	DOCUMENTVIEW
Find location (stigma)	Location
Simple visit	Simplevisit
SIGNATURE	SIGNATURE
Comments of Visit	Comments
Visit Reason	REASON

Action column shows the reserved words (available action types)

sqlOffGetCustomerDetails (configuration)

The SQL to be executed to bring the customer-specific information details in offline mode. It brings the following fields:

field title: the title of every information

field value: the content of information

field Group: Used to group information. Contains the title of the group.

field BusinessType: Specifies the type of information. This field takes the following values:

- PHONENUMBER : indicates that this entry on the customer's details concerns phone number. If the seller presses the entry will be dialing in the specified phone number.

- EMAIL : indicates that the specific record in the customer details concerns an email address. If the seller presses this entry in the list, will open a pop up to choose the email dispatch application wants to use.

- ADDRESSNAVIGATE : The value specified concerns in address. If the seller presses this entry in the list, will open a pop up window to choose the application to view navigation details about this address. (Google maps fully supported).

- Blank (‘’ as BusinessType) : It doesn’t add any functionality to the entry in the list.

If the field BusinessType not set at all (i.e. there is no in select) then the program automatically tries to understand the type of each field. The address can either refers to the name of the road or to the navigation point coordinates.

In case of the coordinates, the field value of select must have the following format:

SELECT ‘navigation point coordinates', ifnull(CentroidX,’’) || "," || ifnull(CentroidY,’’) as value ,'ADDRESSNAVIGATE' as BusinessType FROM ADR WHERE ADRID =$ADRIDDEST$

Mandatory is, the value to have coordinates separated by commas.

Example 1

select 'OUTLET' as title,ifnull(cusname,) as value, as BusinessType from tblServiceCalls inner join CUS on tblServiceCalls.cusid=CUS.cusid where tblServiceCalls.SCid='$SCID$'

UNION ALL select 'CUSTOMER CODE',ifnull(cuscode,), as BusinessType from tblServiceCalls inner join CUS on tblServiceCalls.cusid=CUS.cusid where tblServiceCalls.SCid='$SCID$'

UNION ALL select 'ADDRESS', ifnull(adrstreet,)||','||ifnull(adrdistrict,)||','||ifnull(adrcity,)||','||ifnull(adrzipcode,) as street, 'ADDRESSNAVIGATE' as BusinessType from tblServiceCalls inner join CUS on tblServiceCalls.cusid=CUS.cusid inner join ADR on ADR.adrid=CUS.adriddest WHERE tblServiceCalls.SCid='$SCID$'

UNION ALL select 'Customer COORDINATES', ifnull(CentroidX,)||','||ifnull(CentroidY,) as value, 'ADDRESSNAVIGATE' as BusinessType from tblServiceCalls inner join CUS on tblServiceCalls.cusid=CUS.cusid inner join ADR on ADR.adrid=CUS.adriddest WHERE tblServiceCalls.SCid='$SCID$'

UNION ALL select 'Phone Number', ifnull(adrphone1,) as phone,'PHONENUMBER' as BusinessType from tblServiceCalls inner join CUS on tblServiceCalls.cusid=CUS.cusid inner join ADR on ADR.adrid=CUS.adriddest WHERE tblServiceCalls.SCid='$SCID$'

Example 2

SELECT ‘Customer Code’ AS title

,cuscode AS value

, AS BusinessType

,’Customer Information' AS [Group]

FROM cus WHERE cusid = $CUSID$

UNION ALL SELECT 'Customer Code - main' AS title, leeid AS value

FROM cus WHERE cusid = $CUSID$

UNION ALL SELECT 'Customer Code - Branch' AS title, companyid AS value

FROM cus WHERE cusid = $CUSID$

UNION ALL SELECT 'Α.Φ.Μ.' AS title

,leeafm AS afm

, AS BusinessType

, ’Customer Information' AS [Group]

FROM cus INNER JOIN lee ON cus.leeid = lee.leeid WHERE cusid = $CUSID$

UNION ALL SELECT 'TAX' AS title

,txo.txoname AS txo

, AS BusinessType

, ’Customer Information' AS [Group]

FROM cus

INNER JOIN lee ON cus.leeid = lee.leeid

LEFT OUTER JOIN txo ON lee.txoID = txo.txoID

WHERE cus.cusid = $CUSID$

UNION ALL

SELECT 'Payment method' AS title

,cpmtitle

, AS BusinessType

, ’Customer Information' AS [Group]

FROM cpm INNER JOIN cus ON cus.cpmid = cpm.cpmid WHERE cusid = $CUSID$

UNION ALL

SELECT 'City’ AS title

,adrcity AS value

, AS BusinessType

, ’Address information' AS [Group]
